1D Code Selection Enter/Exit Programming Mode
Product Reference Guide
193
Code 11 Set Length 2
This feature specifies one of the bar code lengths for Code 11 Length Con-
trol. Length 2 is the maximum label length if in Variable Length Mode, or
the second fixed length if in Fixed Length Mode. Length includes the bar
code’s check and da
ta characters.
The length can be set from 2 to 50 char
acters. A setting of 0 specifies to
ignore this length (only one fixed length).
Table 16 provides examples for setting Length 2. See page 283 for detailed
instructions on setting this feature.
Table 16. Code 11 Length 2 Setting Examples
STEP ACTION EXAMPLES
1
Desired Setting (pad with
leading zeroes)
00 (Ignore This
Length)
07 Characters 15 Characters 50 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT CODE 11 LENGTH 2 SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘0’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ and 0’
5 Scan ENTER/EXIT PROGRAMMING MODE
Select Code 11 Length 2 Setting
Make a mistake? Scan the CANCEL bar code to abort
and not save the entry string. You can then start again
at the beginning.
CANCEL
50 = Length 2 is 50 Characters
To Next Page
