References
304
Gryphon™ I GD44XX/GBT4400/GM440X
BT-Only Features
BT Pin Code
This option specifies the 4-character or 16-character pin code to be used
for authentication of the BT link. To set the pin code:
1. Sc
an the ENTER/EXIT PROGRAMMING MODE bar code to enter Program-
ming Mode, then enable "BT Security Mode" on page 259.
2. S
pecify the desired pin code length (4 or 16) by scanning the appropri-
ate bar code in "Select PIN Code Length" on
page 260.
3. Determine the desired characters. For example, D254 or
STOR12345678135M
4. Convert the characters to hexadecimal using the ASCII Chart on the
inside back cover of this manual.
5. Go to page 260 and Scan the bar code: SET 4 CHAR PIN CODE or SET
16-CHAR PIN CODE.
6. Scan the appropriate alphanumeric characters from the keypad in
Appendix D, Keypad, representing the hexadecimal entries determined
in the steps above. You will hear a two-beep indication after the last
c
haracter.
If you make a mistake before the last character, scan the CANCEL bar code
to abort and not save the entry string. You can then start again at the
beginning.
7. Scan the ENTER/EXIT PROGRAMMING MODE bar code to exit Program-
ming Mode.
Changing the pin code setting will unlink the devices. If the Automatic
Configuration Update is set to the default enabled setting, the devices
must only be relinked. If the Automatic Configuration Update is set to the
disabled setting, the Pin Code setting must also be updated in the Base
Station using Aladdin. After the Base Station has been updated, the
devices must be relinked.
Table 47. BT Pin Code Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
D254 STOR12345678135M
2
Convert the characters to
he
xadecimal
44 32 35 34 53 54 4F 52 31 32 33 34 35 36 37 38 31 33 35 4D
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SET BT PIN CODE
5
Scan 8 or 32 Alphanumeric
Character
s From
Appendix D, Keypad
44323534 53544F5231323334353637383133354D
6 Scan ENTER/EXIT PROGRAMMING MODE
