Data Editing
Product Reference Guide
291
Table 36
STEP ACTION EXAMPLES
1. Scan the ENTER/EXIT bar code
(Scanner enters Programming Mode)
2.
Determine placement of the
L
abel ID characters BEFORE or
AFTER with regard to scanned
data using
Label ID
Control, starting on page
93
Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix
3.
Scan the bar code selecting
the sym
bology type you wish
to designate label ID
characters for using
Label ID
Symbology Selection −
1D Symbologies, starting
on page 94
.
DataBar
Omnidirectional
Code 39
Interleaved 2 of
5
Code 32
4.
Custom Label ID example
(desired characters):
D B * = C 3 + P H
5.
Find hex equivalents from the
ASCII Chart
(inside back
cover), then scan in these
digits/character
s using the
bar codes in the section:
Keypad, starting on page
335
. If you make a mistake
before the last character, scan
the CANCEL bar code to abort
and not save the entry string.
You can then start again at
the beginning.
44 42 2A 3D 43 33 2B 50 48
6. Scan the ENTER/EXIT bar code
(Scanner exits Label ID entry)
7.
Scan the ENTER/EXIT bar code
on
ce again
(Scanner exits Programming Mode)
Result:
DB*[bar code
data]
[bar code
data]=C3
+[bar code data] [bar code data]PH
. Label ID Examples
