Standard Cable Pinouts
Product Reference Guide
315
Table 50.
Standard Cable Pinouts — Handheld (GD44XX model) or Base Station (GBT4400
and GM44XX Star models) Side
Pin RS-232 OEM USB
Keyboard
Wedge
1 RTS (out)
2 D+ CLKIN (KBD side)
3 D- DATAIN (KBD side)
4 GND GND GND GND
5 RX
6 TX
7 VCC VCC VCC VCC
8 IBM_B CLKOUT (PC side)
9 IBM_A
DATAOUT (PC
s
ide)
10 CTS (in)
