RF Programming Manual 205
Table 11. Scanner BEEPER Functions
SPEAKER
INDICATION
DURATION COMMENT
Scanner Not
Currently
Linked
Six beeps consisting of 20 ms
on, 20 ms off
Indicates a bar code was read before the scanner was
linked to a Base Station.
Good Read
Beep
100 ms on (short)
250 ms on (medium)
500 ms on (long)
Three programmable functions are available. This indi-
cates a bar code has been read and decoded.
Partial Read
Bip
20 ms on
A very short beep ("bip") is sounded when one bar
code of a two-bar code pair has been successfully
decoded.
Base Station
Acknowledge-
ment Beep
100 ms on (short)
250 ms on (medium)
500 ms on (long)
Indicates a successful bar code transmission to the
host (configurable), a successful change of channel, or
a successful transmission of a new configuration to the
host.
Transmission
Error Beep
High, then low, then high, then
low.
Indicates unsuccessful transmission to the host.
Link Beep
Low, then medium, then high.
Indicates a scanner has been successfully linked to a
base station.
Unlink Beep
High, then medium, then low.
Indicates a scanner has been successfully unlinked
from a base station.
