Datamax E-Class Mark II Programmer's Manual

Extended System-Level Command Functions
100 Class Series 2 Programmer’s Manual
Value Parameter WiFi Interpretation Default Value
M x
Is the maximum transmission rate,
where x:
0 = 1 Mbps
1 = 2 Mbps
2 = 5.5 Mbps
3 = 11 Mbps
2
N y
Is the client name, where:
y = Up to 31 characters, no spaces
N/A
P x
Is the WEP Access Point Density, where
x:
0 = Low
1= Medium
2 = High
0
R y
Is the Region, where:
y = Two-character code; see Appendix T.
US
T x
Is the Mode, where x:
0 = Adhoc
1 = Infrastructure
2 = Unique (SSID = MAC address; and,
WiFi type = Adhoc)
2
V x
Is the DHCP Retransmit Interval, where:
x = 1 to 64 seconds
15
X a
Is MAC Cloning, where a:
0 = Disable
1 = Enable
0
* Each octet must be zero-filled to be properly interpreted (e.g., an IP Address of
10.12.0.243 must be sent to the printer as 010.012.000.243).
Table 5-13 WiFi Setup
Example 1:
<STX>KcNTDN;NTwN;WEI010.012.000.248;WEAEngWAN1;NTI010.012.000.245;NTS25
5.255.000.000;NTG010.012.254.254<CR>

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
