Datamax E-Class Mark II Programmer's Manual

Appendix G – Bar Code Details
218 Class Series 2 Programmer’s Manual
Where:
Field Valid Inputs Meaning
a
1,2,3, and 4 Rotation
W
W Fixed value, extended bar code set
b[b]
c, 1c
Selects the DataMatrix bar code - the two differing values
have no other significance.
c
1 to 9, A to Z, and a to z Module size horizontal multiplier
d
1 to 9, A to Z, and a to z Module size vertical multiplier
eee
000 to 999 No effect; Must be numeric
ffff
0000 to 9999 Label position, row
gggg
0000 to 9999 Label position, column
hhh
000, 050, 080, 100, 140
A 3-digit convolutional error correction level.
If any number other than one of these options is entered
then the nearest lesser value from the valid entries is used.
Example: Selecting an ECC value of 099 will cause the
actual ECC value of 080 to be used.
i
0 - 6
1 digit format identification:
0 - Automatically choose the encodation scheme based
on the characters to be encoded.
1 - Numeric data.
2 - Upper-case alphabetic.
3 - Upper-case alphanumeric and punctuation characters
(period, comma, hyphen, and slash).
4 - Upper-case alphanumeric.
5 - ASCII, the full 128 ASCII character set.
6 - Any 8-bit byte.
If a format identifier is selected which will not encode the
input character stream then the bar code symbol will not be
printed.
Auto-encodation format identification is recommended
since it will select the best possible encodation scheme for
the input stream.
jjj
9, 11, 13 … 49. ECC 140
minimum is 15.
A 3 digit odd number (or 000) of rows requested. 000
causes rows to be automatically determined. If the rows
and columns do not match, the symbol will be sized to a
square using the greater of the two values.
kkk
9, 11, 13 … 49. ECC 140
minimum is 15.
A 3 digit odd number (or 000) of columns requested. 000
causes columns to be automatically determined. If the rows
and columns do not match, the symbol will be sized to a
square using the greater of the two values.
ll…l
8-bit data, followed by a
termination character.
Data to be encoded.
Table G-2: DataMatrix ECC 000 – 140 Record Structure

Datamax E-Class Mark II Specifications

General

Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Operating Temperature	40°F to 95°F (4°C to 35°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
Print Method	Direct Thermal / Thermal Transfer
Max Print Speed	6 inches per second (ips)
Memory	8 MB DRAM
Interface	Serial, Parallel, USB
Media Type	Labels, Tags, Receipts
Media Width	0.75" (19 mm) to 4.65" (118 mm)
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Power Requirements	100-240 VAC, 50-60 Hz
