Page #231 background imageLoading...
Page #231 background image
Appendix G – Bar Code Details
Class Series 2 Programmer’s Manual 219
ECC 200 symbols:
There are 24 square symbol sizes available, with both row and column dimensions,
which may be specified in fields jjj and kkk, measured in modules as indicated in the
following list - 10, 12, 14, 16, 18, 20, 22, 24, 26, 32, 36, 40, 44, 48, 52, 64, 72, 80, 88,
96, 104, 120, 132, and 144. If an ECC 200 symbol is specified with odd numbers of
rows or columns, the next largest even value will be used. Input values greater than
144 or less than 10 will cause the symbol to be automatically sized for the input
character stream. The record format is shown here, expanded with spaces.
a W b[b] c d eee ffff gggg hhh i jjj kkk ll…l
Where:
Field Valid Inputs Meaning
a
1,2,3, and 4 Rotation
W
W Fixed value, extended bar code set
b[b]
c, 1c
Selects the DataMatrix bar code - the two differing values
have no other significance.
c
1 to 9, A to Z, and a to z
Module size horizontal multiplier
d
1 to 9, A to Z, and a to z
Module size vertical multiplier
eee
000 to 999 No effect; Must be numeric
ffff
0000 to 9999 Label position, row
gggg
0000 to 9999 Label position, column
hhh
200 ECC 200 uses Reed-Solomon error correction.
i
0 Fixed value, not used
jjj
10, 12, 14, 16, 18, 20,
22, 24, 26, 32, 36, 40,
44, 48, 52, 64, 72, 80,
88, 96, 104, 120, 132,
144
A 3 digit even number (or 000) of rows requested.
000 causes rows to be automatically determined. The
symbol will be sized to a square if the rows and columns do
not match by taking the larger of the two values.
kkk
10, 12, 14, 16, 18, 20,
22, 24, 26, 32, 36, 40,
44, 48, 52, 64, 72, 80,
88, 96, 104, 120, 132,
144
A 3 digit even number (or 000) of columns requested.
000 causes columns to be automatically determined. The
symbol will be sized to a square if the rows and columns do
not match by taking the larger of the two values.
ll…l
8-bit data Data to be encoded in the symbol
Table G-3: DataMatrix ECC 200 Record Structure
Example:
<STX>L
D11<CR>
1W1c44000010001002000000000DATAMAX<CR>
121100000000100Barcode W1c<CR>
E
Barcode W1c
