SATA Settings details
The SATA Settings screen details are explained as follows:
Option Description
Embedded SATA Enables the embedded SATA option to be set to AHCI Mode, or RAID Mode. This option is set to AHCI Mode by
default.
Security Freeze
Lock
Enables you to send Security Freeze Lock command to the embedded SATA drives during POST. This option is
applicable only for AHCI mode. This option is set to Enabled by default.
Write Cache Enables or disables the command for the embedded SATA drives during POST. This option is set to Disabled by
default.
Port n Enables you to set the drive type of the selected device.
For AHCI Mode or RAID Mode, BIOS support is always enabled.
Option Description
Model Species the drive model of the selected device.
Drive Type Species the type of drive attached to the SATA port.
Capacity Species the total capacity of the drive. This eld is undened for removable media
devices such as optical drives.
NVMe Settings
The NVMe settings enable you to set the NVMe drives to either RAID mode or Non-RAID mode.
NOTE
: To congure these drives as RAID drives, you must set the NVMe drives and the Embedded SATA option in the SATA
Settings menu to RAID mode. If not, you must set this eld to Non-RAID mode.
Viewing NVMe Settings
To view the NVMe Settings screen, perform the following steps:
1 Power on, or restart your system.
2 Press F2 immediately after you see the following message:
F2 = System Setup
NOTE
: If your operating system begins to load before you press F2, wait for the system to nish booting, and then
restart your system and try again.
3 On the System Setup Main Menu screen, click System BIOS.
4 On the System BIOS screen, click NVMe Settings.
NVMe Settings details
The NVMe Settings screen details are explained as follows:
Option
Description
NVMe Mode Enables you to set the NVMe mode. This option is set to Non RAID by default.
54 Pre-operating system management applications
