Removing and installing Field Replaceable
Units (FRUs)
The replaceable components in this chapter are Field Replaceable Units (FRUs).
CAUTION: The information in this section is intended for authorized service technicians only.
CAUTION: To avoid any potential damage to the component or loss of data, ensure that an authorized service
technician replaces the Field Replaceable Units (FRUs).
CAUTION: Dell Technologies recommends that these procedures be performed by trained technical repair
specialists.
CAUTION: Your warranty does not cover damages that may occur during FRU repairs that are not authorized by
Dell Technologies.
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Battery cable
Disconnecting the battery cable
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
About this task
The following image indicates the location of the battery cable and provides a visual representation of the removal procedure.
6
Removing and installing Field Replaceable Units (FRUs) 71
