Chapter 9 Vision Manager
163
9.2.9.1 Extracting features
Operating procedure
1. Choose a target window range to measure.
2. Choose the feature: area, center of gravity, or principal axis.
3. Choose the color: 0-White or 1-Black.
4. Press the Measure button to display the resulting boundaries on the histogram and save
them in the two boundary fields of the Digitization settings screen and display them in the
Vision monitor window.
