13
Chapter 3 Starting Up/Shutting Down
3.1 Loading WINCAPS III
Operating procedure
1. On the Start menu, choose All Programs|DENSO FACTORY WARE|WINCAPS III|WINCAPS
III to display the dialog box for logging in.
2. Specify user level and password.
The user level choices are 0-operator and 1-programmer.
The latter requires a password.
3. Press the Log in button to load WINCAPS III.
