User Manual DEV 1951

114  Copyright DEV Systemtechnik GmbH 2004-2017

 Examples for the occurrence and the sequence of ports in the .portTable:

a) Single switch module installed in the first slot:

Index 1: switch module in the first slot, primary input port ("In A")

Index 2: switch module in the first slot, secondary input port ("In B")

Index 3: "logical" switch module, primary input port

Index 4: "logical" switch module, secondary input port

Index 5: switch module in the first slot, output port ("Out")

Index 6: "logical" switch module, output port

b) Two switch modules installed:

Index 1: switch module in the first slot, primary input port ("In A")

Index 2: switch module in the first slot, secondary input port ("In B")

Index 3: switch module in the second slot, primary input port ("In A")

Index 4: switch module in the second slot, secondary input port ("In B")

Index 5: switch module in the first slot, output port ("Out")

Index 6: switch module in the second slot, output port ("Out")

c) One switch module installed in the first slot and

one distribution amplifier module installed in the second slot:

Index 1: switch module in the first slot, primary input port ("In A")

Index 2: switch module in the first slot, secondary input port ("In B")

Index 3: "logical" switch module, primary input port

Index 4: "logical" switch module, secondary input port

Index 5: switch module in the first slot, output port ("Out")

Index 6: "logical" switch module, output port

Index 7: distribution amplifier module in the second slot, input port

d) Two distribution amplifier modules installed:

Index 1: "logical" switch module 1, primary input port

Index 2: "logical" switch module 1, secondary input port

Index 3: "logical" switch module 2, primary input port

Index 4: "logical" switch module 2, secondary input port

Index 5: "logical" switch module 1, output port

Index 6: "logical" switch module 2, output port

Index 7: distribution amplifier module in the first slot, input port

Index 8: distribution amplifier module in the second slot, input port

5.9.4.3.9.1 .application.portTable.portEntry.portIndex

OID: .1.3.6.1.4.1.21035.41.2.9.1.1.x

Syntax: INTEGER32 (1..256)

Access: not-accessible

Description: A unique value for each table entry ranging between "1" and the

number of entries (defined by .numberOfPorts, chapter 5.9.4.3.8).
