User Manual DEV 1951
128 Copyright DEV Systemtechnik GmbH 2004-2017
6.2.5 Digital Signal Quality Events
If the device is equipped with digital signal modules, the digital signal quality of
each input port is monitored and an event is generated in case that the signal
quality becomes "Fail".
[i] is {1…2} for the input ports of the first digital signal switch module and
[i] is {3…4} for the input ports of the second digital signal switch module.
If distribution amplifier modules for ASI/SDI signals are installed,
[i] is {7} for the input port of the first distribution amplifier module and
[i] is {8} for the input port of the second distribution amplifier module.
Signal Status Port [i] (i = {1…8})
6.2.6 Other Events
For the sake of completeness, the other error codes that might be reported by the
device are listed here. If experiencing one of these events, please contact
DEV Systemtechnik for assistance.
No Communication Module 1
