3.2.11 DEV 11-0058
DPST Sensing Switch Module; DC, 950…2150 MHz; 50 Ohm, SMA (f)
Logic
Out
In A
In B
External
Controller
Out
In A In B
DEV 11-0058
The functionality of the module DEV 11-0058 is identical with the module
DEV 11-0010 (please refer to chapter 3.2.3), but the module is designed for 50 Ohm
with SMA connectors (instead of 75 Ohm with F connectors).
3.2.12 DEV 11-0107
DPST High Power Sensing Switch Module; DC, 950…2150 MHz; 75 Ohm, F (f)
Logic
Out
In A
In B
External
Controller
In A
Out
In B
DEV 11-0107
The functionality of the module DEV 11-0107 is identical with the module
DEV 11-0010 (please refer to chapter 3.2.3), but the module is designed for high
power signals.
3.2.13 DEV 11-0108
DPST High Power Sensing Switch Module; DC, 47…1006 MHz; 75 Ohm, F (f)
Logic
Out
In A
In B
External
Controller
In A
Out
In B
DEV 11-0108
The functionality of the module DEV 11-0108 is identical with the module
DEV 11-0010 (please refer to chapter 3.2.3), but the module is designed for a
different frequency range and for high power signals.
