Rackable Systems management card Setup the Digi CM Unit to support the Rackable Systems management card
Digi CM User Guide 112
.
Field Description
Control
Power status The first column shows the current state.
Three buttons are available to initiate an action to either, power on, power
off or restart the server. Dependant on the current status Power on or Power
off is disabled.
Reboot Reboot the Rackable Server by sending a 500ms reset signal to the server.
Connect Spawn the Java Telnet applet or the local Telnet/SSH application to connect
directly to the port.
LED Mgmt
LED Management To control the LED in the front of the Rackable Server.
The first columns shows the current status of the LED. Three buttons are
available to select the activity of the status LED: turn on, turn off and
blinking. Either of these buttons is disabled.
LCD Mgmt
Currently
displayed message
Shows the message that is currently displayed on the LCD display.
Erase This function clears the LCD display.
The saved message stays saved to flash.
