Digi Connect IT 16 User Manual

Interfaces Wide Area Networks (WANs)
Digi Connect IT® 16/48 User Guide
104
1. Log into the Connect IT 16/48 WebUI as a user with full Admin access rights.
2. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Network > Interfaces.
4. Create the WWAN or select an existing WWAN:
n To create a new WWAN, for Add interface, type a name for the WWAN and click .
n To edit an existing WWAN, click to expand the WWAN.
New WWANs are enabled by default. To disable, click Enable.
5. For Interface type, select Modem.
6. For Zone, select External.
7. For Device, select a cellular modem.
8. Optional WWAN configuration items:
a. For Match SIMby, select a SIM matching criteria to determine when this WWAN should be
used:
n If SIMslot is selected, for Match SIMslot, select which SIM slot must be in active
for this WWAN to be used.
n If Carrier is selected, for Match SIMcarrier, select which cellular carrier must be in
active for this WWAN to be used.
n If PLMN identifier is selected, for Match PLMN identifier, type the PLMN id that
must be in active for this WWAN to be used.
