Hardware
Front panel and LEDs
Item Name Description
1 Power
The LED lights up when the power is supplied to the device and the
device powered on.
n Solid blue: The LEDis solid blue when the power source is
connected and power is being supplied to the device.
n Flashing blue: The Connect IT is shutting down, caused by
pressing the ACPI power button.
n Red: The LED is red when the power supply has failed.
2 Status
The LED lights up when the Connect ITstarts up or you have
activated the Find Me feature.
n Flashing blue: The LED flashes blue once per second when
the Connect IT starts up or you have activated the find me
feature. When starting up, the WWANSignal, WWAN Service,
and Status LEDs on the back of the Connect IT also flash.
n Solid blue: The Connect IT initialization is complete.
n Red: The Connect IThas had start-up failure.
Digi Connect IT® 16/48 User Guide
687
