Digi Connect IT® 16/48 User Guide
183
Search for a port
In the Serial Status page, you can use the Search ports search box to search for a port, or a set of
ports, that match the search entry. The search feature looks for matches in the following columns:
Status, Port, Label, and User.
1. Access the Serial Status page in the web UI.
2. Enter your search entry in the Search ports field. As you type, the ports displayed in the page
are limited to only the ports with information that matches the search entry.
Serial connector pinout in reversed mode
You can configure the serial port’s RJ45 connector to use the reversed mode pinout. In this pinout the
TXD and RXD pins are swapped, and the DCD pin is connected to ground. All other hardware signal pins
(such as RTS/CTS/DTR/DSR) are inactive.
To configure this option, select the Reversed Mode option on the System Configuration page.
Pin Standard mode Reversed mode
1 CTS --
2 DSR --
3 RXD TXD
4 GND GND
5 GND/DCD GND
6 TXD RXD
7 DTR --
8 RTS --
