Digi Connect IT® 16/48 User Guide
674
Configure packet capture for the network analyzer
To use the network analyzer, you must create one or more packet capture configuration.
Required configuration items
n The interface used by this packet capture configuration.
Additional configuration items
n The filter expression for this packet capture configuration.
n Schedule the analyzer to run based on a specified event or at a particular time:
l The events or time that will trigger the analyzer to run, using this capture configuration.
l The amount of time that the analyzer session will run.
l The frequency with which captured events will be saved.
To configure a packet capture configuration:
WebUI
1. Log into the Connect IT 16/48 WebUI as a user with full Admin access rights.
2. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Network > Analyzer.
4. For Add Capture settings, type a name for the capture filter and click .
The new capture filter configuration is displayed.
