Routing Virtual Router Redundancy Protocol (VRRP)

Digi Connect IT® 16/48 User Guide

222

Configure device one (master device)

WebUI

Task 1: Configure VRRP on device one

1. Log into the Connect IT 16/48 WebUI as a user with full Admin access rights.

2. On the menu, click System. Under Configuration, click Device Configuration.

The Configuration window is displayed.

3. Click Network > VRRP.

4. For Add VRRP instance, type a name for the VRRP instance and click .

The new VRRP instance configuration is displayed.
