Digi Connect IT® 16/48 User Guide
172
4. Set the mode:
(config serial USB_port)> mode mode
(config serial USB_port)>
where mode is either:
n login: Allows the user to log into the device through the serial port.
n remote: Allows for remote access to another device that is connected to the serial port.
n application: Provides access to the serial device from Python applications.
n modbus: Allows you to use the serial port for Modbus.
n powerman: Allows you to configure the port for use with a power controller. See
Configure Remote Power Management.
The default is Login.
5. (Optional) Set a label that will be used when referring to this port.
(config serial USB_port)> label label
(config serial USB_port)>
6. If mode is set to login or remote:
a. Set the baud rate used by the device to which you want to connect:
(config serial USB_port)> baudrate rate
(config serial USB_port)>
b. Set the number of data bits used by the device to which you want to connect:
(config serial USB_port)> databits bits
(config serial USB_port)>
c. Set the type of parity used by the device to which you want to connect:
(config serial USB_port)> parity parity
(config serial USB_port)>
Allowed values are:
n even
n odd
n none
The default is none.
d. Set the stop bits used by the device to which you want to connect:
(config serial USB_port)> stopbits bits
(config serial USB_port)>
e. Set the type of flow control used by the device to which you want to connect:
(config serial USB_port)> flow type
(config serial USB_port)
