Virtual Private Networks (VPN) IPsec
Digi Connect IT® 16/48 User Guide
249
(config vpn ipsec tunnel ipsec_example)> local id ipv6_id id
(config vpn ipsec tunnel ipsec_example)>
n rfc822: The ID will be interpreted as an RFC822 (email address).
Set the IDin internet email address format:
(config vpn ipsec tunnel ipsec_example)> local id rfc822_id id
(config vpn ipsec tunnel ipsec_example)>
n fqdn: The ID will be interpreted as FQDN (Fully Qualified Domain Name) and sent as
an ID_FQDN IKE identity.
Set the IDas an FQDN:
(config vpn ipsec tunnel ipsec_example)> local id rfc822_id id
(config vpn ipsec tunnel ipsec_example)>
n keyid: The ID will be interpreted as a Key ID and sent as an ID_KEY_ID IKE identity.
Set the key ID:
(config vpn ipsec tunnel ipsec_example)> local id keyid_id id
(config vpn ipsec tunnel ipsec_example)>
14. Configure the remote endpoint:
a. Set the hostname or IP address of the remote endpoint:
(config vpn ipsec tunnel ipsec_example)> remote hostname value
(config vpn ipsec tunnel ipsec_example)>
If your device is not configured to initiate the IPsec connection (see ike initiate), you can
also use the keyword any, which means that the hostname is dynamic or unknown.
b. Set the ID type:
(config vpn ipsec tunnel ipsec_example)> remote id type value
(config vpn ipsec tunnel ipsec_example)>
where value is one of:
n auto: The ID will be automatically determined from the value of the tunnels
endpoints.
n raw: Enter an IDand have it passed unmodified to the underlying IPsec stack.
Set the unmodified ID that will be passed:
(config vpn ipsec tunnel ipsec_example)> remote id raw_id id
(config vpn ipsec tunnel ipsec_example)>
n any: Any ID will be accepted.
n ipv4: The ID will be interpreted as an IPv4 address and sent as an ID_IPV4_ADDR
IKE identity.
Set an IPv4 formatted ID. This can be a fully-qualified domain name or an IPv4
address.
