Digi Connect IT 16

Virtual Private Networks (VPN) IPsec
Digi Connect IT® 16/48 User Guide
255
where value is one of:
n address: The address of a local network interface.
Set the address:
i. Use the ? to determine available interfaces:
(config vpn ipsec tunnel ipsec_example policy 0)>local address
?
Address: The local network interface to use the address of.
This field must be set when 'Type' is set to 'Address'.
Format:
defaultip
defaultlinklocal
eth1
eth2
loopback
sfp1
sfp2
wwan
Current value:
(config vpn ipsec tunnel ipsec_example policy 0)> local
address
ii. Set the interface. For example:
(config vpn ipsec tunnel ipsec_example policy 0)> local
address eth1
(config vpn ipsec tunnel ipsec_example policy 0)>
n network: The subnet of a local network interface.
Set the network:
i. Use the ? to determine available interfaces:
(config vpn ipsec tunnel ipsec_example policy 0)>local network
?
Interface: The network interface.
Format:
defaultip
defaultlinklocal
eth1
eth2
loopback
sfp1
sfp2
wwan
Current value:
