Digi Connect IT 16

Virtual Private Networks (VPN) Generic Routing Encapsulation (GRE)
Digi Connect IT® 16/48 User Guide
309
Task two: Create an IPsec endpoint interface
WebUI
1. Click Network > Interface.
2. For Add Interface, type ipsec_endpoint1 and click .
3. For Zone, select Internal.
4. For Device, select Ethernet: loopback.
5. Click to expand IPv4.
6. For Address, type the IP address of the local GRE tunnel, 172.30.0.1/32.
7. Click Apply to save the configuration and apply the change.
