User authentication Authentication groups

Digi Connect IT® 16/48 User Guide

505

5. Click Apply to save the configuration and apply the change.

Command line

1. Log into the Connect IT 16/48 command line as a user with full Admin access rights.

Depending on your device configuration, you may be presented with an Access selection

menu. Type admin to access the Admin CLI.

2. At the command line, type config to enter configuration mode:

> config

(config)>

3. At the config prompt, type:

(config)> del auth group groupname

4. Save the configuration and apply the change:

(config)> save

Configuration saved.

5. Type exit to exit the Admin CLI.

Depending on your device configuration, you may be presented with an Access selection

menu. Type quit to disconnect from the device.
