User authentication LDAP
Digi Connect IT® 16/48 User Guide
534
9. (Optional) For Server password, type the password used to log into the LDAP server. Leave
this field blank if the server allows anonymous connections.
10. For User search base, type the distinguished name (DN) on the server to search for users. This
can be the root of the directory tree (for example, dc=example,dc=com) or a sub-tree (for
example. ou=People,dc=example,dc=com).
11. (Optional) For Group attribute, type the name of the user attribute that contains the list of
Connect IT 16/48 authentication groups that the authenticated user has access to. See LDAP
user configuration for further information about the group attribute.
12. For Timeout, type or select the amount of time in seconds to wait for the LDAP server to
respond. Allowed value is between 3 and 60 seconds.
13. Add LDAP to the authentication methods:
a. Click Authentication > Methods.
b. For Add method, click .
c. Select LDAP for the new method from the Method drop-down.
Authentication methods are attempted in the order they are listed until the first successful
authentication result is returned. See Rearrange the position of authentication methods for
information about rearranging the position of the methods in the list.
14. Click Apply to save the configuration and apply the change.
Command line
1. Log into the Connect IT 16/48 command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. (Optional) Prevent other authentication methods from being used if LDAP authentication fails.
Other authentication methods will only be used if the LDAP server is unavailable.
