Page #559 background image
Firewall Port forwarding rules
Digi Connect IT® 16/48 User Guide
559
12. (Optional) Click Access control list to create a white list of devices that are authorized to
leverage this forwarding rule, based on either the IP address or firewall zone:
n To white list IP addresses:
a. Click Addresses.
b. For Add Address, enter an IP address and click .
c. Repeat for each additional IP address that should be white listed.
n To specify firewall zones for white listing:
a. Click Zones.
b. For Add zone, click .
c. For Zone, select the appropriate zone.
d. Repeat for each additional zone.
13. Click Apply to save the configuration and apply the change.
Command line
1. Log into the Connect IT 16/48 command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. At the config prompt, type:
(config)> add firewall dnat end
(config firewall dnat 0)>
Port forwarding rules are enabled by default. To disable the rule:
(config firewall dnat 0)> enable false
(config firewall dnat 0)>
4. Set the network interface for the rule.
(config firewall dnat 0)> interface
(config firewall dnat 0)>
Network connections will only be forwarded if their destination address matches the IP
address of this network interface.
