Interfaces Wide Area Networks (WANs)
Digi Connect IT® 16/48 User Guide
84
g. For Add Interface, type WWAN_Private and click .
h. For Interface type, select Modem.
i. For Zone, select External.
j. For Device, select WWAN cellular modem .
This should be the same modem selected for the WWAN_Public WWAN.
k. Enable APN list only.
l. Click to expand APN list > APN.
m. For APN, type the private APN provided to you by your cellular carrier.
5. Create the routing policies. For example, to route all traffic from LAN1 through the public APN,
and LAN2 through the private APN:
a. Click Network > Routes > Policy-based routing.
b. Click the to add a new route policy.
c. For Label, enter Route through public APN.
d. For Interface, select Interface: WWAN_Public.
e. Configure the source address:
i. Click to expand Source address.
ii. For Type, select Interface.
iii. For Interface, select LAN1.
