In the example, we go to the IO port to sent the IN07 as the “Probe signal”, IN06 as “Negative
Z- axis hard limit signal”:
Figure 4-18 The wiring methods of Probe sensor with over-strock signal
COM+
COM-
COM+
COM-
IN24 IN23 IN22 IN21 IN20 IN19 IN18 IN17 IN16 IN15 IN14 IN13 IN12 IN11 IN10 IN09 IN08 IN07 IN06 IN05 IN04 IN03 IN02 IN01
INPUT
