Digital Dream Standalone Motion Controller DDCS-Expert Users ManualPage-10
DDCS-Expert controller creates a self-defined IO ports method. According to the user’s
favorite, the users can define the input and output ports as which they want. In the IO page,the
users can define the input port and output port, and also can inpect the input/output port and
MPG status.
Power on the DDCS-Expert controller, system popup the main page, and press F4 Key to go
to the IO Port Page:
Page of the IO pop up as below.In the page, you can use the Up/Down arrow, Right/Left
arrive and Knob to select and change the settings.
3 Input and Out Ports
1
2
3
4
5 6 7 8
Figure 3-1 Press F4 to IO Page
Figure 3-2 IO Page
