24 ECY-303 Preloaded Applications
SpaceHumiditySP (AV53)
This variable is used to configure the space/return humidity setpoint.
ID Units Valid Range Default Value
Analog Value 53 %RH 5 to 55%RH 35%RH
DehumiditySP (AV54)
This variable is used to configure the space/return dehumidity setpoint to control the cooling stages.
ID Units Valid Range Default Value
Analog Value 54 %RH 40 to 95%RH 55%RH
DischHumiditySP (AV55)
This variable is used to configure the discharge humidity high limit setpoint.
ID Units Valid Range Default Value
Analog Value 55 %RH 50 to 95%RH 85%RH
MaxRangeCO2 (AV56)
This variable is used to configure the maximum scaling of UI7 or UI8 when configured for SpaceCO2
or ReturnCO2. The range of the input can be configured using UI7Range(MSV21) or
UI8Range(MSV22)
ID Units Valid Range Default Value
Analog Value 56 ppm N/A 2000ppm
MinRangeCO2 (AV57)
This variable is used to configure the minimum scaling of UI7 or UI8 when configured for SpaceCO2
or ReturnCO2. The range of the input can be configured using UI7Range(MSV21) or
UI8Range(MSV22)
ID Units Valid Range Default Value
Analog Value 57 ppm N/A 0ppm
ComSensorSpOffset (AV58)
This variable is used to display the actual EC-Smart-Vue or EC-Smart-Comfort setpoint offset value.
ID Units Valid Range Default Value
Analog Value 58 Delta-Degrees-Celsius (∆°C) - AV87 to AV87 0∆°C
FanOnSetpoint (AV59)
This variable is used to configure the on trigger value used to calculate a digital fan status when UI6 is
configured for FanCurrent.
ID Units Valid Range Default Value
Analog Value 59 Amperes (A) >0A 1 A
FanOffSetpoint (AV60)
This variable is used to configure the off trigger value used to calculate a digital fan status when UI6 is
configured for FanCurrent.
