23ECY-303 Preloaded Applications
MaxFanCurrent (AV45)
This variable is used to configure the maximum scaling of UI6 when configured for FanCurrent. The
range of the input can be configured using UI6Range(MSV20).
ID Units Valid Range Default Value
Analog Value 45 Amperes (A) N/A 10 A
ChgOverDelay (AV46)
This variable is used to configure the minimum delay between heating/cooling.
ID Units Valid Range Default Value
Analog Value 46 minutes N/A 1 min
BypassTime (AV47)
This variable is used to configure the bypass delay when the room occupancy is overridden either via
the EC-Sensor-SO, the EC-Smart-Comfort or the EC-Smart-Vue.
ID Units Valid Range Default Value
Analog Value 47 minutes N/A 120 min
MaxOatHeat (AV48)
This variable is used to configure the outdoor temperature above which the heating stages are dis-
abled.
ID Units Valid Range Default Value
Analog Value 48 Degrees-Celsius (°C) N/A 18°C
MinOatHeat (AV49)
This variable is used to configure the outdoor temperature below which the compressor stages are
disabled.
ID Units Valid Range Default Value
Analog Value 49 Degrees-Celsius (°C) N/A 10°C
EffectSp(AV50)
This variable is used to display the actual setpoint used by the control algorithm. This value is based
on the occupancy status (MSV15) and the actual cooling and heating setpoints (AV36 and AV37)
ID Units Valid Range Default Value
Analog Value 50 Degrees-Celsius (°C) N/A N/A
TempErr(AV51)
This variable is used to display the actual deviation of the temperature from the setpoint.
ID Units Valid Range Default Value
Analog Value 51 Delta-Degrees-Celsius (∆°C) N/A N/A
CO2Setpoint (AV52)
This variable is used to configure the CO2 setpoint.
ID Units Valid Range Default Value
Analog Value 52 ppm N/A 1000 ppm
Variables
