Operation
Operating Instructions 867-M PREMIUM - 00.0 - 02/2015 19
5Operation
5.1 Switching power supply on and off
The lower main switch (4) on the controller regulates the power
supply.
Fig. 2: Switching power supply on and off
Switching power on
1. Press the main switch (4) down to position I.
Indicator lamps (1) and (3) light up.
Switching power off
1. Press the main switch (4) up to position 0.
Indicator lamps (1) and (3) turn off.
Switching on the dimmable sewing lamp
1. Press switch (5) to the left to position 1.
2. Press switch (2) up to position 1.
Dimmable sewing lamp illuminates.
Switching off the dimmable sewing lamp
1. Press switch (2) down to position 0.
2. Press switch (5) to the left to position 0.
(1) - Indicator lamp on the keypad
(2) - Switch for dimmable sewing lamp
(3) - Indicator lamp on the controller
(4) - Main power switch
(5) - Switch for the sewing lamp
①
②
④
③
⑤
