Operation
Operating Instructions 867-M PREMIUM - 00.0 - 02/2015 27
Winding
1. Switch on the sewing machine.
2. Press the foot pedal forwards.
The machine sews and winds the hook thread from the
thread reel onto the bobbin.
When the bobbin is full, the machine automatically stops
winding. The bobbin lever moves down.
The cutter is automatically moved into its basic vertical
position.
3. Pull off the full bobbin.
4. Tear off the thread behind the cutter.
5. Insert the full bobbin in the hook
( Kap. 5.5 Replacing the hook thread bobbin, p. 27).
6. Repeat the winding-on procedure with an empty bobbin, as
described above.
5.5 Replacing the hook thread bobbin
Fig. 10: Replacing the hook thread bobbin
WARNING
Risk of injury from needle and moving parts!
Switch off the sewing machine before replacing
the hook thread bobbin.
(1) - Slot
(2) - Guide
(3) - Tensioning spring
(4) - Slot
(5) - Bobbin
(6) - Bobbin housing flap
