DURKOPP ADLER 867-M Premium - Technical Data; Data Overview by Submodel

Technical Specifications
Operating Instructions 867-M PREMIUM - 00.0 - 02/2015 7
2.4 Technical data
2.4.1 Data overview by submodel
Submodels: 867-M PREMIUM
-190922-M -190929-M -190942-M -190945-M
Stitch type Double lockstitch 301
Hook type Vertical hook,
large (L)
Vertical hook,
extra-large (XXL)
Number of needles 1
Needle system 134-35
Needle strength [Nm] 90 - 180
Maximum thread strength [Nm] 120/3 - 10/3 (STC: 15/3 max)
Stitch length, forwards / backwards
[mm]
12 / 12
Adjustable stitch lengths 1
Maximum s.p.m. 3800 3400
Number of stitches on delivery 3400
Maximum sewing foot stroke 9
Maximum stroke height 20
Mains voltage [V] 230
Mains frequency [Hz] 50 / 60
Length/width/height [mm] 740/220/460
Weight [kg] 59
