Setup
Operating Instructions 867-M PREMIUM - 00.0 - 02/2015 49
7.6 Setting the working height
The working height is continuously adjustable between 750 and
900 mm (clearance between the floor and upper edge of the table
top).
Fig. 28: Setting the working height
1. Release the screws (1) on the frame bars.
2. Set the table top to the desired height.
Important: Pull out or push in the table top evenly at both
sides to prevent it from jamming.
3. Tighten the screws (1) on the frame bars.
CAUTION
Risk of crushing!
The table top can sink under its own weight when
the screws on the frame bars are released. This
applies even more when the machine head is
already fitted.
Ensure that your hands are not jammed when
releasing the screws.
