Operation
Operating Instructions 867-M PREMIUM - 00.0 - 02/2015 31
1. Press the foot pedal (1) halfway back.
The machine stops and raises the sewing feet.
The sewing feet remain up as long as the foot pedal
is pressed halfway back.
or
1. Press the foot pedal (1) fully back.
The thread cutter is activated and
the sewing feet are raised.
5.8 Sewing backwards with the stitch adjust-
ment lever (optional)
The electronic stitch adjustment lever on the machine arm reduces
the stitch length down to sewing backwards in the lower end
position.
Fig. 15: Stitch adjustment lever on the machine arm
1. Slowly push the stitch adjustment lever (1) down.
The stitch length becomes smaller. In the lower
end position, the machine sews in reverse with the
currently set stitch length.
(1) - Stitch adjustment lever
①
