Setup
Operating Instructions 867-M PREMIUM - 00.0 - 02/201562
7.14Lubrication
All wicks and felt bits of the machine head are soaked in oil at the
factory. This oil is conveyed to the reservoir during use. This is
why you should avoid filling too much oil during initial filling.
Fig. 40: Oil level indicator
1. Fill oil through the filler hole (1) to a maximum of 2 mm below
the maximum level marking (2).
Required oil:
Only DA 10 or equivalent oil should be used for the machine, which
has the following properties:
• Viscosity at 40 °C: 10 mm²/s
• Flash point: 150 °C
WARNING
Skin damage due to contact with oil!
Oil can cause a rash if it comes into contact with
skin.
Avoid any skin contact with the oil.
If oil has come into contact with your skin, wash
the affected areas thoroughly.
(1) - Filler opening
(2) - Maximum level marking
(3) - Minimum level marking
NOTICE
Machine damage possible due to incorrect oil level.
Too little or too much oil can damage the machine.
During initial filling, only pour in oil up to 2 mm below the
maximum level marking.
