Technical Specifications
Operating Instructions 867-M PREMIUM - 00.0 - 02/2015 5
2 Technical Specifications
2.1 Characteristics
The Dürkopp Adler 867-M PREMIUM is a flatbed sewing machine
for double lockstitches.
General technical characteristics
• 1-needle machine
• Large or extra-large vertical hook
• Transport: Bottom feed, needle transport and alternating
foot-top feed
• Programmable setting of the stitch length via stepper motor
• Programmable adjustment of the alternating sewing feet via
stepper motor
• Programmable sewing foot pressure via stepper motor (in
combination with compression spring)
• Sewing foot lifter controlled by stepper motor
• Programmable, electronically regulated thread tension (ETT)
• Electronic handwheel (jog dial)
• DC drive for all submodels
• Safety snap-on coupling for preventing any misadjustment of
or damage to the hook in the event of a thread jamming
• Automatic wick lubrication for machine and hook with oil
level indicator at the column
• Maximum passage with ventilated sewing feet: 20 mm
• Electromagnetic thread cutter,
Short thread cutter (length of remaining thread approx.
5 mm) or long thread cutter (length of remaining thread
approx. 32 mm)
• Keypad on the machine arm and favorite button for quick
functions
• Direct drive positioned on top of the arm shaft
2.2 Declaration of Conformity
The machine complies with the European regulations specified in
the Declaration of Conformity or in the Declaration of Incorporation.
