Settings via the software
Operating Instructions 867-M PREMIUM - 00.0 - 02/2015 71
8.4.2 Menu for other settings
1. Use / to select Other parameters.
2. Press the OK key.
3. Use / to select the desired parameter.
4. Press the OK key to select the parameter.
5. Change values using the / keys.
6. Press the OK key to confirm your selection.
7. Press or ESC to exit the menu.
Resetting the bobbin stitch counter
The defined maximum s.p.m. of the bobbin used is
reset to zero.
Symbol Meaning
Symbol Meaning
Max Speed (speed)
Value range: 100 to 3800
Thread Trim (thread cutter)
Value range: on/off
Thread Clamp (thread clamp)
Value range: on/off
Point Position (initial alignment stitch)
Value range: 0 to 360°
Start Tack (bartack at the start of a seam)
Dialog box for defining the start bar tack
End Tack (bartack at the end of a seam)
Dialog box for defining the end bar tack
