Operation
Operating Instructions 867-M PREMIUM - 00.0 - 02/2015 21
Changing the needle
Fig. 3: Inserting and replacing the needle
1. Turn the handwheel until the needle bar (1) reaches the upper
end position.
2. Loosen the screw (2).
3. Pull the needle out towards the bottom.
4. Insert the new needle.
5. Important: Align the needle so that the groove (3)
is facing the hook (4).
6. Tighten the screw (2).
1
2
3
4
(1) - Needle bar
(2) - Screw
(3) - Groove
(4) - Hook
