Settings via the software
Operating Instructions 867-M PREMIUM - 00.0 - 02/2015 69
Sewing foot pressure
Value range: 1 to 20
•Use
/ to select the Sewing foot pressure
parameter.
•Use
/ to change the sewing foot pressure
Stroke height
Value range: 0 to 9 mm (0.5 mm increments)
•Use
/ to select the Stroke height parameter.
•Use
/ to change the stroke height
Other parameters
8.4.2 Menu for other settings, p. 71
S.p.m. or seam length in mm
After the thread has been cut off, the display is
retained. Measurement/counting restarts when sewing
starts again.
P Creating a program
8.6.1 Creating programs, p. 75
+/- No function assigned
ESC, F and S No function assigned
OK No function assigned
Symbol Meaning
