Eaton EASY-E4 Series User Manual

Cycle pulse
Falling edge 130
Rising edge 129
Cycle time 267, 280, 403, 471
D
D - Text display
Bar graph 369
Date and time display 373
Date and time entry 378
Display and input elements 368
Latching button 377
Message text 372
Message text selection 378
Rolling text 371
Running text 370
Static text 370
Timing relay value display 374
Timing relay value entry 378
Value display 368
Value entry 375
D - Text display (Display) 357, 366
Damage
Missing parts 40
Data block 306, 311
Data function block 317
Data logger 380
Data multiplexer 322
Date and time display 373
Date and time entry 378
Date setting 482
DB 317
Q1 (boolean function block output) 317
DC 272
Debounce 469
Deceleration ramp 294
Decimal numbers 397
Declarations 583
Default colors display 361
Defining password-protected areas 476
Delay value 279
DELETE
Function blocks 160
Deleting
Operands at function block inputs/outputs 159
Rung 139
Derivative term 273
Description 19
Destination address 311
Destination range 307, 312
Detecting or changing bit patterns 353
Determining counter frequency 224
Device
Changing language 79
Device versions 22-23
Diagnostics
Using diagnostic bits 571
Dimension 580
Directives 583
Display 528
Default colors 361
Elements 357
Display and input elements 368
Display elements 357
Display messages 568
Display priority 360
Disposal
Recycling 577
DIV 250
Dividing 251
DL - Data logger 380
Download 362
easyE4 11/18 MN050009 EN www.eaton.com
593

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
