Eaton PowerXL DC1 - Dc1-12

6 Technical Data
6.2 Specific rated operational data
DC1 Variable Frequency Drive 04/16 MN04020003Z-EN www.eaton.com 135
6.2.2 DC1-12…device series
Size Symbol Unit
2D3 4D3 7D0NN
7D0FN
7D0NB
7D0FB
011 015
Rated operational current I
e
A 2.3 4.3 7 7 10.5 15
Overload current for 60 s every 600 s i
l
A
3.45 6.45 10.5 10.5 15.75 22.5
Starting current for 2 s every 20 s A
4.03 7.53 12.25 12.25 18.38 26.25
Apparent power at rated operation
230 V
SkVA
0.92 1.71 2.79 2.79 4.18 5.98
Apparent power at rated operation
240 V
SkVA
0.96 1.79 2.91 2.91 4.36 6.24
Assigned motor power
at 230 V, 50 Hz P kW 0.37 0.75 1.5 1.5 2.2 4
at 220 - 240 V, 60 Hz P HP
0.5 1 2 2 3 5
Power side (primary side):
Number of phases single-phase or two-phase
Rated operating voltage U
LN
V
200 - 10 % - 240 + 10 %, 50/60 Hz
180 - 264 ±0 %, 48 - 62 Hz ±0 %
Input current (phase current) I
LN
A
3.7 7.5 12.9 12.9 19.2 29.2
Minimum braking resistance R
B
Ω
– – – 100 50 25
Switching frequency (pulse frequency)
Default Setting f
PWM
kHz 16 16 16 16 16 8
Setting range f
PWM
kHz
4 -32 4 -32 4 -32 4 -32 4 -32 4 -24
Maximum leakage current to earth
(PE), Without motor
I
PE
mA
2.49 2.49 2.49 2.49 2.49 < 1
Efficiency η
0.95 0.94 0.96 0.96 0.95 0.96
Heat dissipation at I
e
(150 %) P
V
CO
18.5 45.75 63 63 103.4 160
fan, built-in
– ✓ ✓ ✓ ✓ ✓
Size
FS1 FS1 FS1 FS2 FS2 FS3
