Eaton PowerXL DC1 - Frame Sizes FS1 to FS3 in IP66

6 Technical Data
6.3 Dimensions
142 DC1 Variable Frequency Drive 04/16 MN04020003Z-EN www.eaton.com
6.3.3 Frame sizes FS1 to FS3 in IP66
Figure 78: Dimensions for DC1 with IP66 degree of protection (NEMA 4X)
Table 22: Dimensions, weights, and sizes for IP66
REV FWD
0
ON
OFF
PWR
b
a c
a1
c1
b1b2
a1
b1
 1
 2
a1
b1
Frame size a a1 b b1 b2 c c1 ⌀1 ⌀2 m
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
kg
(lbs)
FS1 161
(6.34)
148.5
(5.85)
232
(9.13)
189
(7.44)
25
(0.98)
184
(7.24)
3.5
(0.14)
4
(0.15)
8
(0.31)
2.8
(6.17)
FS2
188
(7.4)
176
(6.93)
257
(10.12)
200
(7.87)
28
(1.1)
192
(7.56)
3.5
(0.14)
4.2
(0.16)
8.5
(0.33)
5
(11.02)
FS3
210
(8.27)
197.5
(7.78)
310
(12.2)
252
(9.92)
33
(1.3)
234
(9.21)
3.5
(0.14)
4.2
(0.16)
8.5
(0.33)
8.2
(18.08)
1 in = 1’’ = 25.4 mm, 1 mm = 0.0394 in
