Eaton PowerXL DC1 - Cable Cross-Sections

6 Technical Data
6.4 Cable cross-sections
DC1 Variable Frequency Drive 04/16 MN04020003Z-EN www.eaton.com 143
6.4 Cable cross-sections
The “Maximum terminal capacity” specification indicates the maximum
possible sizes that can be connected to the power terminals. The cross-
sectional areas and gauges that should be used for the power supply and
motor connections are recommendations for the corresponding frame sizes
and ratings and are provided as examples.
Table 23: Cable cross-sections
￫
Use the general installation instructions and local conditions as a
basis when selecting terminal capacities.
Device Type
Frame
size
Maximum
terminal capacity
Input current
I
LN
Cross-sectional area/
gauge that should be
used for the power
supply (L1/L, L2/N, L3, PE)
Output
current (rated
operational
current) I
e
Cross-sectional area/
gauge that should be
used for the motor
connection (U, V, W, PE)
mm
2
AWG/
kcmil
1)
A mm
2
AWG/
kcmil
1)
A mm
2
AWG/
kcmil
1)
Mains voltage 115 V
Supply voltage (50/60 Hz) U
LN
110 (-10 %) - 115 (+10 %) V
U
e
115 V AC, single-phase / U
2
230 V AC, three-phase (internal voltage doubler)
DC1-1D2D3…
FS1 8 8 7.8 2.5 14 2.3 1.5 14
DC1-1D4D3…
FS1 8 8 15.8 4 10 4.3 1.5 14
DC1-1D5D8…
FS2 8 8 21.9 6 8 5.8 1.5 14
Mains voltage 230 V
Supply voltage (50/60 Hz) U
LN
200 (-10 %) - 240 (+10 %) V
U
e
230 V AC, single-phase / U
2
230 V AC, three-phase
DC1-122D3…
FS1 8 8 3.7 1.5 14 2.3 1.5 14
DC1-124D3…
FS1 8 8 7.5 1.5 14 4.3 1.5 14
DC1-127D0NN…
FS1 8 8 12.9 2.5 12 7 1.5 14
DC1-127D0FN…
FS1 8 8 12.9 2.5 12 7 1.5 14
DC1-127D0NB…
FS2 8 8 12.9 2.5 12 7 1.5 14
DC1-127D0FB…
FS2 8 8 12.9 2.5 12 7 1.5 14
DC1-12011…
FS2 8 8 19.2 4 10 10.5 1.5 14
DC1-12015…
FS3 8 8 29.2 4 8 15 2.5 12
Mains voltage 230 V
Supply voltage (50/60 Hz) U
LN
200 (-10 %) - 240 (+10 %) V
U
e
230 V AC, three-phase / U
2
230 V AC, three-phase
DC1-322D3…
FS1 8 8 3.4 1.5 14 2.3 1.5 14
DC1-324D3…
FS1 8 8 5.6 1.5 14 4.3 1.5 14
DC1-327D0NN…
FS1 8 8 9.5 1.5 14 7 1.5 14
DC1-327D0NB…
FS2 8 8 8.9 1.5 14 7 1.5 14
DC1-327D0FB…
FS2 8 8 8.9 1.5 14 7 1.5 14
DC1-32011…
FS2 8 8 12.1 2.5 12 10.5 1.5 14
DC1-32018…
FS3 8 8 20.9 6 10 18 2.5 10
DC1-32024…
FS3 8 8 26.4 10 8 24 4 10
DC1-32030…
FS4 16 5 33.3 16 8 30 6 8
