1 DC1 device series
1.4 Rated operational data
14 DC1 Variable Frequency Drive 04/16 MN04020003Z-EN www.eaton.com
1.4.2 Key to part numbers
The catalog no. or part no. for the DC1 series of variable frequency drives is
made up of four sections.
Series – Power section – Model – Version
The following figure shows it in greater detail:
Figure 5: Key to part numbers
1) Please refer to manual MN04020004Z-EN
D C 1 - 1 2 4 D 1 F N - A 2 0 N Explanation
Type
N = basic device
Degree of protection
20 = IP20 / NEMA 0
66 = IP66 / NEMA 4X
6S = IP66 with switch / NEMA 4X, switched
Display unit (display)
A = LED display
Brake Chopper
N = No internal brake chopper
B = Brake chopper
EMC (radio interference suppression filter)
N = No internal RFI filter
F = Internal RFI filter
Rated operational current (examples)
2D2 = 2.2 A
4D1 = 4.1 A
046 = 46 A
Mains voltage category
1 = 115 V (110 - 115 V ±10 %)
2 = 230 V (200 - 240 V ±10 %)
4 = 400 V (380 - 480 V ±10 %)
D = 115 V input / 230 V output (voltage doubler)
Connection in power section
1 = Single-phase mains connection / three-phase motor
3 = Three-phase mains connection / three-phase motor
S = Single-phase mains connection / single-phase motor
Device series
DC1 = variable frequency drive, compact, Series 1
(D = Drives, C = Compact, 1 = Series)
