1 DC1 device series
1.4 Rated operational data
16 DC1 Variable Frequency Drive 04/16 MN04020003Z-EN www.eaton.com
1.4.3 Features
1.4.3.1 DC1-1D…device series
Mains voltage: 1 AC 110 - 115 V (±10 %), 50/60 Hz
Output voltage: 3 AC 230 V, 50/60 Hz
￫
An internal voltage doubler will increase the mains supply
voltage to 230 V (output voltage).
Type
Rated
operational current
Assigned Instance
Motor Power
Display
(operating unit)
Local controls
Radio interference
suppression filter
Degree of protection
Size
Brake chopper
I
e
P
1)
(230 V,
50 Hz)
P
2)
(230 V,
60 Hz)
A kW HP
DC1-1D2D3NN-A20N 2.3 0.37 1/2 LED – – IP20 FS1 –
DC1-1D2D3NN-A66N
2.3 0.37 1/2 LED – – IP66 FS1 –
DC1-1D2D3NN-A6SN
2.3 0.37 1/2 LED ✓ – IP66 FS1 –
DC1-1D4D3NN-A20N
4.3 0.75 1 LED – – IP20 FS1 –
DC1-1D4D3NN-A66N
4.3 0.75 1 LED – – IP66 FS1 –
DC1-1D4D3NN-A6SN
4.3 0.75 1 LED ✓ – IP66 FS1 –
DC1-1D5D8NN-A20N
5.8 1.1 1-1/2 LED – – IP20 FS2 ✓
DC1-1D5D8NN-A66N
5.8 1.1 1-1/2 LED – – IP66 FS2 ✓
DC1-1D5D8NN-A6SN
5.8 1.1 1-1/2 LED ✓ – IP66 FS2 ✓
1) As per IEC standards
2) As per UL 61800-5-1, Table DVE.1, March 6, 2015
