6 Technical Data
6.2 Specific rated operational data
136 DC1 Variable Frequency Drive 04/16 MN04020003Z-EN www.eaton.com
6.2.3 DC1-32… device series
Size Symbol Unit
2D3 4D3 7D0NN 7D0NB
7D0FB
Rated operational current I
e
A 2.3 4.3 7 7
Overload current for 60 s every 600 s i
l
A
3.45 6.45 10.5 10.5
Starting current for 2 s every 20 s A
4.03 7.53 12.25 12.25
Apparent power at rated operation
230 V
SkVA
0.92 1.71 2.79 2.79
Apparent power at rated operation
240 V
SkVA
0.96 1.79 2.91 2.91
Assigned motor power
at 230 V, 50 Hz P kW 0.37 0.75 1.5 1.5
at 220 - 240 V, 60 Hz P HP
0.5 1 2 2
Power side (primary side):
Number of phases 3 3 3 3
Rated operating voltage U
LN
V
200 - 10 % - 240 + 10 %, 50/60 Hz
180 - 264 ±0 %, 48 - 62 Hz ±0 %
Input current (phase current) I
LN
A
3.4 5.6 9.5 8.9
Minimum braking resistance R
B
Ω
– – – 100
Switching frequency (pulse frequency)
Default Setting f
PWM
kHz 16 16 16 16
Setting range f
PWM
kHz
4 -32 4 -32 4 -32 4 -32
Maximum leakage current to earth
(PE),
Without motor
I
PE
mA
< 1 < 1 < 1 < 1
Efficiency η
0.96 0.95 0.96 0.96
Heat dissipation at I
e
(150 %) P
V
CO
14.8 39.75 61.5 61.5
fan, built-in
– ✓ ✓ ✓
Size
FS1 FS1 FS1 FS2
